31 ACS2000 AFE 2MVA UM 3BHS355653 ZAB E01 REV. H
2.1 Overview
The air-cooled ACS2000 is a general purpose frequency converter for
the control of standard induction motors.
The following picture provides an overview of the
available ACS2000 2MVA AFE drives.
The following sections provide an overview of:
• the available main and auxiliary power configu-
rations,
• the power electronic components of the drive,
• the cooling system,
• cabinet features such as the grounding switch
and the electro-mechanical door interlock.
For information on the power and voltage
range of the drive, see the technical spec-
ifications and / or the rating plate of the
drive.
2-1 Overview of ACS2000
2MVA AFE drives
2-1
• ACS2000 for connection to a non-integrated transformer
• ACS2000 for connection to an integrated transformer (1)
• ACS2000 for direct-to-line connection (DTL)
