CHAPTER 4 – TRANSPORTATION, STORAGE AND DISPOSAL 76
4.4.3 Using hand pallet trucks
Observe the following points when transporting
the cabinet:
• Place a pallet truck on the left and on the right
of the cabinet.
Capacity and fork length for pallet trucks:
• Insert the forks fully to transport the cabinet.
• Make sure that the forks are on the same
height.
Pallet Truck 1 2, 3, 4
Capacity 3000 kg 2000 – 2200 kg
Fork length 2 m 1 m
4-3 Transporting the
cabinet by pallet trucks
