ABB ACS380 Series Quick Start Up Guide

17
ACS380 Minimum required parameter settings PROFIBUS DS
The minimum required parameter settings based on factory default settings.
Parameter
Description
Setting
Comment
50.01
FBA A Enable
Enable
Activates fieldbus module
51.02
NODE
ADDRESS
[PB NODE]
PROFIBUS DP node address of the drive
51.05
PROFILE
1
Communication profile ABB drives
52.02
FBA data in2
Act1 16bit (5)
Actual speed as Data Word 2 from the drive
53.02
FBA data out2
Ref1 16bit (2)
Speed reference as Data Word 2 to the drive
51.27
FBA par refresh
Configure
Updates fieldbus settings (groups 50 to 57)
20.01
Ext 1
commands
Fieldbus A
Fieldbus interface as source for start and stop
22.11
Ext1 speed ref1
FB A ref1
Fieldbus interface as source for speed reference
31.11
Fault reset
selection
P.06.01 bit 7
Fieldbus interface as source for fault reset
(46.01)
Speed scaling
[Scale max]
Max speed/frequency scaling value (used in
function block/visualization input
SPEED_REF_MAX). Must be less or equal to
drive parameter max speed/frequency.
