Program features 125
Amplitude logger 1 is fixed to monitor motor current, and cannot be reset. With
amplitude logger 1, 100% corresponds to the maximum output current of the drive
(I
max
, as given in the hardware manual). The measured current is logged
continuously. The distribution of samples is shown by parameters 36.20…36.29.
Settings
Parameter group 36 Load analyzer (page 334).
Percentage of samples
<10%
10…20%
20…30%
30…40%
40…50%
50…60%
60…70%
70…80%
80…90%
>90%
Amplitude ranges
(parameters 36.40…36.49)
