Fieldbus control through the embedded fieldbus interface (EFB) 609
Setting up the embedded fieldbus interface
Set the drive up for the embedded fieldbus communication with the parameters
shown in the table below. The Setting for fieldbus control column gives either the
value to use or the default value. The Function/Information column gives a
description of the parameter.
Parameter
Setting for
fieldbus control
Function/Information
COMMUNICATION INITIALIZATION
58.01 Protocol enable Modbus RTU Initializes embedded fieldbus communication.
Drive-to-drive link operation is automatically
disabled.
EMBEDDED MODBUS CONFIGURATION
58.03 Node address 1 (default) Node address. There must be no two nodes
with the same node address online.
58.04 Baud rate 19.2 kbps (default) Defines the communication speed of the link.
Use the same setting as in the master station.
58.05 Parity 8 EVEN 1 (default) Selects the parity and stop bit setting. Use the
same setting as in the master station.
58.14 Communication
loss action
Fault (default) Defines the action taken when a
communication loss is detected.
58.15 Communication
loss mode
Cw / Ref1 / Ref2
(default)
Enables/disables communication loss
monitoring and defines the means for
resetting the counter of the communication
loss delay.
58.16 Communication
loss time
3.0 s (default) Defines the timeout limit for the
communication monitoring.
58.17 Transmit delay 0 ms (default) Defines a response delay for the drive.
58.25 Control profile ABB Drives
(default),
Transparent
Selects the control profile used by the drive.
See section Basics of the embedded fieldbus
interface (page 613).
58.26
…
58.29
EFB ref1 type
…
EFB act2 type
Auto, Transparent,
General, Torque,
Speed, Frequency
Selects the reference and actual value types.
With the Auto setting, the type is selected
automatically according to the currently active
drive control mode.
58.30 EFB status word
transparent
source
Other Defines the source of status word when 58.25
Control profile = Transparent.
58.31 EFB act1
transparent
source
Other Defines the source of actual value 1 when
58.28 EFB act1 type = Transparent or
General.
58.32 EFB act2
transparent
source
Other
Defines the source of actual value 2 when
58.29 EFB act2 type = Transparent or
General.
