506 Additional parameter data
01.70 Ambient temperature % Real -200.00 … 200.00 % 100 = 1%
(Parameters 01.102…01.164 only visible when IGBT supply unit control activated by 95.20)
01.102 Line current Real 0.00 … 30000.00 A 100 = 1 A
01.104 Active current Real 0.00 … 30000.00 A 100 = 1 A
01.106 Reactive current Real 0.00 … 30000.00 A 100 = 1 A
01.108 Grid frequency Real 0.00 … 100.00 Hz 100 = 1 Hz
01.109 Grid voltage Real 0.00 … 2000.00 V 100 = 1 V
01.110 Grid apparent power Real -30000.00 … 30000.00 kVA 100 = 1 kVA
01.112 Grid power Real -30000.00 … 30000.00 kW 100 = 1 kW
01.114 Grid reactive power Real -30000.00 … 30000.00 kvar 100 = 1 kvar
01.116 LSU cos Φ Real -1.00 … 1.00 - 100 = 1
01.164 LSU nominal power Real 0…30000 kW 1 = 1 kW
03 Input references
03.01 Panel reference Real -100000.00 … 100000.00 - 100 = 1
03.02 Panel reference 2 Real -30000.00 … 30000.00 - 100 = 1
03.05 FB A reference 1 Real -100000.00 … 100000.00 - 100 = 1
03.06 FB A reference 2 Real -100000.00 … 100000.00 - 100 = 1
03.07 FB B reference 1 Real -100000.00 … 100000.00 - 100 = 1
03.08 FB B reference 2 Real -100000.00 … 100000.00 - 100 = 1
03.09 EFB reference 1 Real -30000.00 … 30000.00 - 100 = 1
03.10 EFB reference 2 Real -30000.00 … 30000.00 - 100 = 1
03.11 DDCS controller ref 1 Real -30000.00 … 30000.00 - 100 = 1
03.12 DDCS controller ref 2 Real -30000.00 … 30000.00 - 100 = 1
03.13 M/F or D2D ref1 Real -30000.00 … 30000.00 - 100 = 1
03.14 M/F or D2D ref2 Real -30000.00 … 30000.00 - 100 = 1
04 Warnings and faults
04.01 Tripping fault Data 0000h…FFFFh - 1 = 1
04.02 Active fault 2 Data 0000h…FFFFh - 1 = 1
04.03 Active fault 3 Data 0000h…FFFFh - 1 = 1
04.04 Active fault 4 Data 0000h…FFFFh - 1 = 1
04.05 Active fault 5 Data 0000h…FFFFh - 1 = 1
04.06 Active warning 1 Data 0000h…FFFFh - 1 = 1
04.07 Active warning 2 Data 0000h…FFFFh - 1 = 1
04.08 Active warning 3 Data 0000h…FFFFh - 1 = 1
04.09 Active warning 4 Data 0000h…FFFFh - 1 = 1
04.10 Active warning 5 Data 0000h…FFFFh - 1 = 1
04.11 Latest fault Data 0000h…FFFFh - 1 = 1
04.12 2nd latest fault Data 0000h…FFFFh - 1 = 1
04.13 3rd latest fault Data 0000h…FFFFh - 1 = 1
04.14 4th latest fault Data 0000h…FFFFh - 1 = 1
04.15 5th latest fault Data 0000h…FFFFh - 1 = 1
No. Name Type Range Unit FbEq32
