Parameters 159
11.60 Freq out 1 at src
min
Defines the minimum value of frequency output 1. See
diagrams at parameter 11.58 Freq out 1 src min.
0 Hz
0…16000 Hz Minimum value of frequency output 1. 1 = 1 Hz
11.61 Freq out 1 at src
max
Defines the maximum value of frequency output 1. See
diagrams at parameter 11.58 Freq out 1 src min.
16000 Hz
0…16000 Hz Maximum value of frequency output 1. 1 = 1 Hz
11.81 DIO filter time Defines a filtering time for parameters 11.01 DIO status and
11.02 DIO delayed status. The filtering time will only affect the
DIOs that are in input mode.
10.0 ms
0.3 … 100.0 ms Filtering time for 11. 01. 10 = 1 ms
12
12 Standard AI
Configuration of standard analog inputs.
12.01 AI tune Triggers the analog input tuning function.
Connect the signal to the input and select the appropriate
tuning function.
No action AI tune is not activated. 0
AI1 min tune Current analog input AI1 signal value is set as minimum value
of AI1 into parameter 12.17 AI1 min. The value reverts back to
No action automatically.
1
AI1 max tune Current analog input AI1 signal value is set as maximum
value of AI1 into parameter 12.18 AI1 max. The value reverts
back to No action automatically.
2
AI2 min tune Current analog input AI2 signal value is set as minimum value
of AI2 into parameter 12.27 AI2 min. The value reverts back to
No action automatically.
3
AI2 max tune Current analog input AI2 signal value is set as maximum
value of AI2 into parameter 12.28 AI2 max. The value reverts
back to No action automatically.
4
12.03 AI supervision
function
Selects how the drive reacts when an analog input signal
moves out of the minimum and/or maximum limits specified
for the input.
The supervision applies a margin of 0.5 V or 1.0 mA to the
limits. For example, if the maximum limit for the input is
7.000 V, the maximum limit supervision activates at 7.500 V.
The inputs and the limits to be observed are selected by
parameter 12.04 AI supervision selection.
Note: Analog input signal supervision is only active when
• the analog input is set as the source (using the AI1 scaled
or AI2 scaled selection) in parameter 22.11, 22.12, 22.15,
22.17, 23.42, 26.11, 26.12, 26.16, 26.25, 28.11, 28.12,
30.21, 30.22, 40.16, 40.17, 40.50, 41.16, 41.17, 41.50 or
44.09, and is being used as the active source, or
• supervision is forced using parameter 12.05 AI supervision
force.
No action
No action No action taken. 0
Fault Drive trips on 80A0 AI supervision.1
Warning Drive generates an A8A0 AI supervision warning. 2
No. Name/Value Description Def/FbEq16
