Installation
31
If many cables are connected to the terminals on the lower side of the circuit-
breaker, the arc monitoring should have with an additional detector located
just behind the front protective sheet, see the figure below.
• Attach the detector directly to the bottom side of the bracket of the protective
cover with a cable strap.
