Technical data
75
Settings and indications
Connections for HMI on Arc Monitor 1 output RJ45 male at front side
1 output RJ14 female at the right side)
Display on HMI 52 x 26 mm graphic LCD with LED backlight
Keyboard on HMI Membrane buttons, 4 soft key
LED signal on HMI Power, Trip, Error
LED signal on Arc Monitor and extension module Power, Trip
configuration switches 8 - pole DIP switch on Arc Monitor front
Settings (HMI) Time and display language
Configuration (DIP switches)
Manual or auto reset of K2 and K3
Use of CSU or not
trip configuration
Display information Trip log, connected modules, actual configuration
self diagnostic test result and error log
Power supply
Rated supply voltage,U
s 100-240 V AC 50-60 Hz
100-250 V DC
U
s variation AC - 20% - +10%
DC - 25% - + 30%
Rated insulation voltage, U
s 250 V with reinforced insulation
Rated impulse withstand voltage U
s 4 kV
Main MCB/fuse Max. 10 A char. C/fuse 10 A gG
Power cunsumption 5 W
Reaction time
From light detection to trip contacts ( K4, K5 ,K6) Approx. 1ms (depends on light intensity)
From light detection to trip signal relays (K2, K3) < 10 ms
Current condition from input to output <0,4 ms
Start-up time
Trip possible < 15 ms from power on
Detector
Maximum length 30 m with AM and extension - E1
60 m with extension - E3
Service temperature range - 25 to + 70 °C continous
- 25 to + 85 °C short-time
Smallest permissible bending radius 45 mm after installation
10 mm on handling
Acceptable backlight intensity light without tripping 3000 Lux
Optical cable for connecting CSU to an Arc Monitor
Maximum length 30 m
