SUPPORT SERVICES
RECOMMENDED SPARE PARTS
9 - 2
NOTE:
1
Kit contains SEM screw NBMMA13006A as of Novem-
ber 2009/Serial Number 3K620000029936.
Table 9-3. AV Diaphragm Assembly Kit No. 258486_2
1
(for Types AV15 and AV16)
Item Part No. Qty Description Item Part No. Qty Description
20 5400288_5 1 Small diaphragm 24 5400294_1 1 Diaphragm ring
22 5400292_1 1 Diaphragm
spacer
73 5400288_4 1 Large diaphragm
(AV15)
23 5400293_1 1 Diaphragm
support (AV15)
73 5400283_6 1 Large diaphragm
(AV16)
23 5400293_2 1 Diaphragm
support (AV16)
Table 9-4. Filter Replacement Kit No. 258487_1
(positioners equipped with optional manifold, Type AV___1/2___)
Part No. Qty Description
19984_1 1 O-ring lubricant
5311428_1 3 O-rings
5400057_1 3 Filters
Table 9-5. Pilot Valve Assembly Kit No. 258488_1
(for Types AV11, AV12 and AV2)
Item Part No. Qty Description
3 5400259_1 1 Valve stem
4 5400260_1 1 Valve body
5 5400261_1 1 Valve clip
35 1951398_12 3 O-rings
— 19984_1 1 O-ring lubricant
Table 9-6. Pilot Valve Assembly Kit No. 258488_2
(for Types AV15 and AV16)
Item Part No. Qty Description
3 5400259_1 1 Valve stem
4 5400260_1 1 Valve body
5 5400261_1 1 Valve clip
35 1951779_010 3 O-rings
— 19984_1 1 O-ring lubricant
