APPENDIX B - QUICK START
INTRODUCTION
This section is intended for control engineers with in-depth knowl-
edge of positioners and positioner applications. This quick start
only highlights the primary tasks involved in installation and opera-
tion. Section 1 through Section 5, in the main body of this instruc-
tion address installation and operation in more detail.
PRODUCT IDENTIFICATION (NOMENCLATURE)
Table B-1. Nomenclature
Position123456789
Type A V
_______
Characterizable Positioners
1
Characterizable Pneumatic Positioner
2
Characterizable 4 to 20-mA Input Positioner (actuator moves to 0%
or 100% upon loss of signal)
Input Signal
1 20.7 to 103.4 kPa (3.0 to 15.0 psig) (Type AV1)
2 20.7 to 186.2 kPa (3.0 to 27.0 psig) (Type AV1)
3 4 to 20 mA (standard intrinsically safe Type AV2)
5 20.7 to 103.4 kPa (3.0 to 15.0 psig), high temperature applications
(Type AV1)
1
6 20.7 to 186.2 kPa (3.0 to 27.0 psig), high temperature applications
(Type AV1)
1
7 4 to 20 mA with explosionproof I/P converter (NEMA 7) (Type AV2)
2
Stroke/Rotary Motion (cam selection)
1 12.7 to 50.8 mm (0.5 to 20.0 in.) or 45° rotary motion
2 25.4 to 101.6 mm (1.0 to 4.0 in.) or 90° rotary motion
Manifold (includes filters)/Gage Block
0 No manifold
1 Manifold with equalizing valve, filters and gage ports (required for dou-
ble acting actuators with manual override)
2 Manifold with equalizing valve inoperable (includes filters and gage
ports)
3
3 Gage block (gage port only)
1
Position Transmitter
0 None (must be 0 for Types AV15, AV16 and AV27)
1 Potentiometric resistive output
2 4 to 20-mA output
