SUPPORT SERVICES
ADDITIONAL SPARE PARTS
9 - 4
Table 9-12. Manifold Assembly Kit No. 258491_1
(replaces 5400282_1 or 5400282 _2 (for replacement or field addition, Type AV___1/2___))
Item Part No. Qty Description Item Part No. Qty Description
17 5400282
_1 1 Manifold assembly 67 NBAHA16024 2 Manifold screws
64 5311428_207 4 Manifold O-rings — 19984_1 1 O-ring lubricant
65 NTJHA09030 4 Manifold washers — 5400066_1 1 Valve plate
1
66 NBAHA16020 4 Manifold screws
NOTE:
1. Used to make equalizing valve handle inoperable for Type AV___2___positioner applications. Discard for Type
AV1__1___positioner applications.
Table 9-13. Cam Follower Arm Kit No. 258544 _1
(replaces part no. 5400306 _1)
Part No. Qty Description
258544_1 1 Cam Follower- Arm Assembly
Table 9-14. Cover Assembly Kit No. 258545_1
(for Types AV11, AV12 and AV2 — replaces part no. 5400258_1)
Item Part No. Qty Description Item Part No. Qty Description
1 5400254
_1 1 Cover 4 5400257_1 1 Cover insert
2 5400255
_1 1 Window 5 5400257_2 1 Cover insert
3 5400256
_1 1 Gasket 6 1964033 _1 1 Styleplate
Table 9-15. Cover Assembly Kit No. 258545_1
(for Types AV15 and AV16 — replaces part no. 5400258_1)
Item Part No. Qty Description Item Part No. Qty Description
1 5400254
_1 1 Cover 5 5400257_2 1 Cover insert
2 5400255
_1 1 Window 6 1964033_1 1 Styleplate
4 5400257
_1 1 Cover insert 10 R9025-0046 1 Silicon tubing
Table 9-16. Gage Block Assembly Kit No. 258569_1
(for replacement or field addition, Types AV11 _3, AV12 _3 and AV2__3)
Item Part No. Qty Description Item Part No. Qty Description
1 5400318
_1 1 Manifold, gage 6 5311428_207 4 O-rings
2 NKJHA16004 3 Set screw, socket
hex hdlss cup pnt
7 NBAHA16020 3 Screw, hex socket
head cap
5 1951041_4 2 Pipe plug, socket
head
8 NTJHA09030 3 Lockwasher,
spring
Table 9-17. Gage Block Assembly Kit No. 258569_3
(for replacement or field addition, Types AV15_3 and AV16)_3)
Item Part No. Qty Description Item Part No. Qty Description
1 5400318
_1 1 Manifold, gage 6 1951779_207 4 O-rings
2 NKJHA16004 3 Set screw, socket
hex hdlss cup pnt
7 NBAHA16020 3 Screw, hex socket
head cap
