SUPPORT SERVICES
ADDITIONAL SPARE PARTS
9 - 13
25 5400295_1 Diaphragm cover 80 07958063 I/P converter
26 5400296
_1 Exhaust mesh 81 1943187_2 Cable clip (2 req)
27 193243
_1 Large position transmitter gear 82 NDPAC15004 Pan head screw
28 1951652
_1 Barb fitting (2 req) 83 1951747_1 T-fitting
29 Refer to Table 9-31 Plug button 84
30 197120
_28 Cam nut 85 197860_1 Cable strap
31 19734
_45 Washers
1
86 MP409-393 Label, terminal block
32 197777
_50 Retaining ring, cam (2 req) 88 6638288_1 Barb fitting filter
33 197164
_18 Retaining ring, span 90 MP409-393 Connection label
34 197227
_1 Special hex head sems screw 91 6639479_1 4 to 20-mA position xmttr assy
1
35 1951398_12 O-ring (3 req) 92 197893_1 Thread forming screw
1
36 197843_1 Fastener, push-on, removable 93 R9023-0205 Heat shrink tubing
37 1945750
_1 Pull plug (3 req) 94 1946162_4 Pin receptacle
38 5400072
_2 Knife base 95 5400268_2 Bracket, pot mounting
1
39 5400073_1 Knife edge 96 193242_1 Small position transmitter gear
1
40 NBZHA21014 Cover screw 98 1951755_1 Bumper grommet (3 req)
41 NBZHA21040 Cover screw 99 1951755
_2 Bumper grommet (2 req)
42 NBAHA15006 Hinge screw (4 req) 100 NTMHA13000 Lock washer
43 NPSHA05000 Hairpin clip (2 req) 101 MP409-393 Label, position transmitter
1
44 NTBTF13150 Teflon washer (3 req) 102 197893_1 Thread forming screw
1
45 NBAHA13006 Diaphragm cover screw (4 req) 103 5400317_1 Gear adapter
1
46 197865_2 Stroke adjustment screw 104 NKJHA13004 Socket head cup pt set screw
1
47 197865_1 Stroke adjustment screw 105 NKJHA16004 Socket head cup pt set screw
1
48 NKJHA16004 Zero adjustment set screw 106 1951041_4 Socket head pipe plug
1
49 NBAHA16020 Span adjustment screw 107 NKJHA23006 Socket head cup pt set screw
1
50 1951041_1 Socket head pipe plug 108 1951631_206 O-ring
51 NIDHA13005 Indicator screw 109 258567
_1 NEMA 4X kit
1
52 NIDHA15012 Pilot valve screw (2 req) 110 5400264_2 Hinge
53 NBMHA13006 Diaphragm support screw
2
NOTE:
1. Refer to Tables 9-31, 9-32 and 9-33 for quantities.
2. Items 53 & 54 replaced by SEM screw NBMHA13006A as of November 23, 2009/Serial Number 3K620000029936
Table 9-31. Cam and Drive Shaft Parts Reference for
Type AV2 Positioners (Fig. 9-4)
Type
Item (Part Number) Item (Quantity)
41314296331
1
34 107 109
AV231__00 5400260_1 5400289_1,2 5400287_1 114B095U01 5327445_2 2 1 Omit Omit
AV231
__0N 5400260_1 5400289_1,2 5400287_1 1943573_1 5327445_22 1 2 1
AV231
__0P 5400260_2 5400289_1,2 5400287_1 114B095U01 5327445_2 2 1 Omit Omit
AV231
__10 5400260_1 5400289_1,2 5400278_1 114B095U01 5327445_1 2 Omit Omit Omit
AV231
__1N 5400260_1 5400289_1,2 5400278_1 1943573_1 5327445_12Omit2 1
AV231
__1P 5400260_2 5400289_1,2 5400278_1 114B095U01 5327445_1 2 Omit Omit Omit
AV231
__20 5400260_1 5400289_1,2 5400287_2 114B095U01 Omit 2 Omit Omit Omit
AV231
__2N 5400260_1 5400289_1,2 5400287_2 1943573_1Omit2Omit21
AV231
__2P 5400260_2 5400289_1,2 5400287_2 114B095U01 Omit 2 Omit Omit Omit
Table 9-30. Type AV2 Positioner Parts List for Figure 9-4 (continued)
Item Part No. Description Item Part No. Description
