ABB AX400 Series Manual

5
Serial Profibus
-----
CONFIG. SERIAL
-----
CONFIG. SECURITY
Slave Address
5
CONFIG. COMMS
CONFIG. CONTROL
Serial Profibus
Configure Serial Communications
Refer to relevant User Guide and access the CONFIG. SERIAL page.
Communications System Protocol
Select Serial Profibus for use in a PROFIBUS system.
Slave Address
Enter the slave address assigned to the analyzer (within the range 0 to 125).
Return to main menu.
Single input analyzer and option board not fitted – see Configure Control
Section in relevant User Guide.
Dual input analyzer and option board not fitted – see
Security Section in
relevant User Guide.
3 NETWORK CONNECTION AND CONFIGURATION
3.2 Network Configuration
Note. An AX400 Series analyzer is not configured using PROFIBUS commands but via the analyzer's keypad and menu
system. Configure the analyzer for PROFIBUS communication as shown below.
