21.4.1 Process Supply Voltage
CAUTION!
The process supply voltage must be included in the earthing concept (e. g.
earthing of the minus pole).
21.4.2 Inputs
Fig. 33: Example for connection input Ix
AC500-S Safety User Manual
For a detailed description of the electrical connection of the module, please
refer to the "AC500-S Safety User Manual".
Example
2019/11/15 3ADR024117M02xx, 11, en_US 169
