Fig. 19: Example for connection output AOx
Fig. 20: Example for connection input DIx
Fig. 21: Example for connection output DOx
11.5 Cleaning
Cleaning instruction
Do not use cleaning agent for cleaning the device.
Use a damp cloth instead.
11.6 Certification
Example Analog
Output
Example Digital
Input
Example Digital
Output
2019/11/15 3ADR024117M02xx, 11, en_US 95
