26.4.1 Process Supply Voltage
CAUTION!
The process supply voltage must be included in the earthing concept (e. g.
earthing of the minus pole).
26.4.2 Inputs/Outputs
Fig. 37: Example for connection input Ix
Examples
Connection > Inputs/Outputs
2019/11/15 3ADR024117M02xx, 11, en_US 207
