29.4 Connection
1 Status displays (7-segment)
2 Triangle displays for ”Item”
3 Square displays for ”Status”
4 Status LEDs
5 Function keys
6 MC: Slot for the SD Memory Card
7 TA525: Label
8 The connection part may be different on various terminal base types. See installation
instructions of the specific terminal base suitable for this CPU for connection specifications.
Sign for XC version
Processor modules PM56xx-2ETH can only be used with TB56xx-2ETH
terminal bases.
For PM5610-2ETH, no communication module or safety module SM560 can be
added.
Only the following terminal base can be used:
– TB5600-2ETH
2019/11/153ADR024117M02xx, 11, en_US226
