CoriolisMaster FCB330, FCB350, FCH330, FCH350 | CI/FCB300/FCH300-EN Rev. F 35
Chan ge from tw o to one c olum n
7 Ex relevant specifications acc. to ATEX / IECEx / NEPSI
7.1 Electrical data
7.1.1 Overview of the different output options
Versions ATEX, IECEx, NEPSI Zone 2 ATEX, IECEx, NEPSI Zone 1
Version I
Output option A1, A2, H1, H2
in the order number
— Current output 1: Active
— Current output 2: Passive
— Pulse output: Active / passive, switchable
—
Switching input and output: Passive
— Current output 1: Active
— Current output 2: Passive
— Pulse output: Passive
— Switching input and output: Passive
Version II
Output option A3, H3
in the order number
— Current output 1: Passive
— Current output 2: Passive
— Pulse output: Passive
—
Switching input and output: Passive
7.1.2 Version I: Active / passive current outputs
Model FCx3xx-A1, FCT3xx-A1 or FCx3xx-A2, FCT3xx-A2 or FCx3xx-S2, FCT3xx-S2
Type of protection
"nA" (Zone 2)
General operating
values
Type of protection
"e" (Zone 1)
Type of protection "ib"
(Zone 1)
Current output 1, active
Terminals 31 / 32
Terminal 32 is connected to
"PA"
U
i
(V) I
i
(mA) U
b
(V) I
b
(mA) U (V) I (mA) U
o
(V)
I
o
(mA)
P
o
(mW)
C
o
(nF)
C
o
pa
(nF)
L
o
(mH)
20 100 500 217 0 3.8
30 30 30 30 60 35 U
i
(V)
I
i
(mA)
P
i
(mW)
C
i
(nF)
C
i
pa
(nF)
L
i
(mH)
60 100 500 2.4 2.4 0.17
Current output 2, passive
Terminals 33 / 34
Terminal 34 is connected to
"PA"
30 30 30 30 60 35 30 100 760 2.4 2.4 0.17
Pulse output, passive
Terminals 51 / 52
30 65 30 65 60 35 15 30 115 2.4 2.4 0.17
Switching output, passive
Terminals 41 / 42
30 65 30 65 60 35 15 30 115 2.4 2.4 0.17
Switching input, passive
Terminals 81 / 82
30 10 30 10 60 35 30 60 500 2.4 2.4 0.17
All inputs and outputs are electrically isolated from one other and from the power supply. Only current outputs 1 and 2 in zone 1
design are not electrically isolated from one another.
