40 CI/FCB300/FCH300-EN Rev. F | CoriolisMaster FCB330, FCB350, FCH330, FCH350
8 Ex relevant specifications acc. to cFMus
8.1 Overview of the different output options
Versions
Class I Div. 2
Class I Div. 1
Version I
Output option A1, A2, H1, H2
in the order number
— Current output 1: Active
— Current output 2: Passive
— Pulse output: Active / passive, switchable
—
Switching input and output: Passive
— Current output 1: Active
— Current output 2: Passive
— Pulse output: Passive
— Switching input and output: Passive
Version II
Output option A3, H3
in the order number
— Current output 1: Passive
— Current output 2: Passive
— Pulse output: Passive
—
Switching input and output: Passive
8.2 Electrical data for Div. 2 / Zone 2
8.2.1 Version I: Active / passive current outputs and Version II: passive / passive current outputs
Model FCx3xx-F2, FCT3xx-F2
Type of protection NI
Vmax
o
(V)
Imax
o
(mA)
Current output 1
Terminals 31 / 32
30 30
Current output 2
Terminals 33 / 34
30 30
Pulse output
Terminals 51 / 52
30 65
Switching output
Terminals 41 / 42
30 65
Switching input
Terminals 81 / 82
30 10
All inputs and outputs are electrically isolated from one other and from the power supply.
