11 CP620, CP630, CP635, CP651, CP661, CP665, CP676
Technical Data
Model CP620-x (-WEB) CP630-x (-WEB)
Display/Backlight TFT Color / LED TFT Color / LED
Colors 64 K 64 K
Resolution 480 x 272 320 x 240
Diagonal (inches) 4.3” 5.7“
Dimming Yes Yes
Touchscreen Yes Yes
User memory flash 128 MB 128 MB
SC card slot Yes Yes
Recipe memory Yes. Flash memory storage limited
only by available memory
Yes. Flash memory storage limited
only by available memory
Serial Port RS-232, RS-485, RS 422, DB9
female, software configurable
RS-232, RS-485, RS 422, DB9
female, software configurable
Ethernet port 2 x 10/100 Mbit/s with integrated
switch
2 x 10/100 Mbit/s with integrated
switch
USB port 1 x host interface, version 2.0 and
1.1
2 x host interface,
1 version 2.0 and 1.1,
1 version 2.0
Expansion slot for future
optional plugin modules
1 x 2 x
Battery Rechargeable Rechargeable
Real-time clock Yes Yes
Voltage 18 … 32 V DC *) 18 … 32 V DC *)
Current rating (at 24 V DC) 0.4 A 0.65 A
Weight 1 kg 1 kg
*) For applications not requiring compliance with EN 61131-2 and specifically in reference to 10 ms voltage
dips, the minimum power supply voltage is 10 V DC.
