7 CP620, CP630, CP635, CP651, CP661, CP665, CP676
Technical Specifications
Parameter Value
Touchscreen technology Resistive
Back-up battery 3V 50mAh Lithium, rechargeable, not user-replaceable, model VL2330
Fuse Automatic
Serial Port RS-232, RS-485, RS-422 software configurable
User memory Flash 128 MB for CP620, CP630, CP635 including –x, -x-WEB
Flash 256 MB for CP635-Fx,
Flash 256 MB for CP651, CP661, CP665, CP676 including –x, -x-WEB
Recipe memory Flash
Hardware clock Clock/calendar with back-up battery
Accuracy RTC
(at 25 °C operating)
< 100 ppm
Environmental Conditions
Parameter Value According to
Operating temperature
(surrounding air temperature)
0 °C … +50 °C
for CP635-Fx: -20 °C … +60 °C
EN 60068-2-14
Storage temperature -20 °C … +70 °C
for CP635-Fx: -40 °C … +85 °C
EN 60068-2-14
Operating and storage humidity 5 % … 85 % RH not-condensing EN 60068-2-30
Vibrations 5 Hz … 9 Hz, 7 mm
p-p
9 Hz … 150 Hz, 1 g
EN 60068-2-6
Shock ± 50 g, 11 ms, 3 pulses per axis EN 60068-2-27
Protection class IP66 front panel *
for CP635-Fx: IP69K
EN 60529
*) The front face of the Control Panel unit, installed in a solid panel, has been tested using conditions
equivalent to the standards shown in the ”Environmental Conditions”. Even though the CP600 unit’s level
of resistance is equivalent to these standards, oils that should have no effect on the control panel can
possibly harm the unit. This can occur in areas where either vaporized oils are present, or where low vis-
cosity cutting oil are allowed to adhere to the unit for long periods of time. If the control panel’s front face
protection sheet becomes peeled off, these conditions can lead to the ingress of oil into the control panel
and separate protection measures are suggested.
If the installation gasket is used for a long period of time, or if the unit and its gasket are removed from the
panel, the original level of the protection cannot be guaranteed.
