CP1484, CP1485, CP1486, CP3484, CP3485, CP3486
11Data sheet V 1.00
CP3484, CP3485, and CP3486
1.1.7 Slot for program memory
Program memory is required to operate the CPUs. The program memory is CompactFlash. It is
not included with the delivery of the CPUs, instead it must be ordered as an accessory.
Figure 2: X20 CPUs - operating elements for CP3484, CP3485, and CP3486
Mounting rail
latch
Operating mode
switch
CompactFlash LED status indicators
IF1 - RS232
Exchangeable
fan (CP3486)
Ethernet
station address
IF2 -
IF3 -
IF4 - USB
IF5 - USB
Slots for
interface
modules
Terminal block for CPU
and I/O feed,
RS232 connection
Ethernet
ETHERNET
Powerlink
Battery
