L2234
Emax
108/158
Model
Scale
Page No.
Doc. No.
Apparatus
1SDH000460R0002
L2778
The surfing path is summarized in the following table:
14.5.5.1 Test Menu table
Parameter / Function Values Notes
CB status Open/Closed/Indefinite Indefinite in case of fault only
Auto Test Display test
Trip Test Enabled/Disabled
PR120/D-M State of springs Loaded/Unloaded
Module Position of CB Isolated/Withdrawn
Open CB
Close CB
PR120/K Input ON
Module Auto Test - - -
Zone Protection S/DFW
selectivity (status) Input ON/OFF
Force Output
Release Output
Protection G/ DBW
(status) Input ON/OFF
Force Output
Release Output
14.5.6Information Menu
The Information Menu enables you to view the data relating to the protection unit and the type of circuit-breaker.
1/3
Protection Unit
Nr. :
Version
Normative
Software
00000000000ABB SACE
: LSIG
:IEC
: P 1.02
Device
: PR123/P
1/3
Circuit Breaker
Device
Nr. :
Rated Curr.
Installation
Maintenance
: E1B800
: 630 A
: Jan 00, 2000
: Jan 00, 2000
1/2
Protection Unit
Circuit Breaker
Protection Unit
About
Enter ↵
ESC +↓
+ Enter ↵
14.5.6.1 Information on the trip and opening data
The PR123/P unit saves all the information relating to the type of protection tripped, the opening data, the date and time. Using the "i Test" key
makes the release show all these data directly on the display. There is no need for an auxiliary power supply for this function. With an auxiliary
power supply, the information is shown immediately on the display without the need to press the "i Test" key and remains displayed indefinitely
until you press the key.
The information remains available for 48 hours with dead relay. The data relating to the last 20 trips are stored in the unit's memory. By connecting
a PR030/B battery unit and PR010/T or a BT030 wireless communication unit, you can retrieve the information relating to the last 20 trips recorded.
Access to view the opening data is via the Historicals submenu in the Measurements menu. The following is an example of the information provided:
Again in the Measurements menu, you can view the percentage of contact wear, which is an indication of the electrical life of the electrical contacts
in the circuit-breaker.
In any case, functionality of the relay is in no way modified by the presence of the wear messages.
The prealarm message (wear > 80%, "warning" LED lighting up) indicates that the wear has reached a high value. The alarm message (100%
wear, "alarm" LED lighting up) indicates that it is necessary to check the state of contact wear.
The percentage of wear depends on the number of openings carried out by the circuit-breaker and by the absolute current interrupted during
each of them.
1/3
Last Trip
15 Feb 2004
I1: 625A
I2: 617A
N: > 10.0 kA
L Protection
N.02
I3: 623A
Number of openings due to the protections and to the TRIP tests.
Indication for protection tripped.
Value of the currents interrupted on phases (L1, L2, L3), neutral (Ne) and Ground (if G has been tripped).
