L2234
Emax
119/158
Model
Scale
Page No.
Doc. No.
Apparatus
1SDH000460R0002
L2778
15.1.7 Electrical characteristics of the transformers
If the phase-to-phase line voltage is greater than 690Vac, it is essential to use a step-down transformer between the bars and the PR120/V
module. Voltage transformers can be installed up to 15m away from the PR120/V module to which they are connected. Proper operation is
only guaranteed for star/star or delta/delta configurations.
The allowable primary and secondary rated voltages that must be set on the unit are specified in the table 15.1.5.2.
Mechanical characteristics
Fixture DIN rail EN 50022
Material self-extinguishing thermoplastic
Degree of protection IP30
Electrostatic protection shielded towards EARTH
Electrical characteristics
Precision class cl. 0.5
Performance ≥10 VA...≤20 VA
Overload 20% permanent
Insulation 4 kV between inputs and outputs
4 kV between shield and outputs
4 kV between shield and inputs
Operating frequency range from 50Hz to 60Hz, ± 10%
