13.4.4 Default settings
The PR122/P is supplied by ABB SACE with the following predefined parameters:
# Protection On/Off Thresholds Time Curve T.M. ZS Trip
1 L -- 1In 144s I
2
t Off -- --
2 S Off 6In 50ms K -- Off: 0.04s --
3 I On 4In -- -- -- -- --
4 G Off 0.2In 0.4s K -- Off: 0.04s On
5 U (currents) Off 50% 5s Off
6 OT -- Off
7 K LC1 Off 50% I
1
8 K LC2 Off 75% I
1
9 UV Off 0.9Un 5s Off
10 OV Off 1.05Un 5s Off
11 RV Off 0,15Un 15s Off
12 RP Off - 0.1Pn 10s Off
13 UF Off 0.9Fn 3s Off
14 OF Off 1.1Fn 3s Off
15 Language -- Engl
16 Net Frequency -- 50Hz
17 PR021/K Off
18 Neutral sel. -- *
19 Toroid Selec. -- None
20 Ext. ground tor. Off 100A
21 Rated Voltage -- 380V/400V/690V
22 S startup Off 6In 100ms
23 I startup Off 4In 100ms
24 G startup Off 1In 100ms
25 Password -- 0001
26 Measuring interval -- 60 min
27 Iw Off 3In
28 Power direction -- top → bottom
29 Harmonic distortion Off
warning
30 MCR Off 6In 40ms -- -- -- --
Note:
* = Off for 3-pole versions
* = 50% for 4-pole versions
* = 100% for full-size versions
