24 EasyLine EL3000 Series Commissioning Instructions
Analyzer(s) Test gas for the zero-point calibration
and the single-point calibration
Test gas for the end-point
calibration
Limas23 with calibration cells
(automatic calibration)
N
2
or air or
UV sample component-free gas
Calibration cells or
test gas for each sample
component
Limas23 without calibration
cells (automatic calibration)
N
2
or air or
UV sample component-free gas
Test gas for each sample
component
Limas23 without calibration
cells (manual calibration)
N
2
or air or
UV sample component-free gas
Test gas for each sample
component
Limas23 + Magnos206 or
oxygen sensor with
calibration cells
(automatic calibration, i.e.
Magnos206 with single-point
calibration)
N
2
or oxygen- and
UV sample component-free gas
Either calibration cells and test
gas for oxygen detector or
test gas for each sample
component, respectively for each
detector
Limas23 + Magnos206 or
oxygen sensor without
calibration cells
(automatic calibration)
N
2
or oxygen- and
UV sample component-free gas
Test gas for each sample
component, respectively for each
detector
Limas23 + Magnos206 or
oxygen sensor without
calibration cells
(manual calibration)
N
2
or oxygen- and
UV sample component-free gas
Test gas for each sample
component, respectively for each
detector
Magnos206
Oxygen-free process gas Process gas with known O
2
concentration
Magnos206 with suppressed
measuring range
Test gas with O
2
concentration near the
starting point of the measuring range
Test gas with O
2
concentration
near the end point of the
measuring range
Magnos206 with single-point
calibration
Test gas with O
2
concentration in an
existing measuring range or ambient air.
Same moisture content as process gas.
–
Magnos206 with substitute
gas calibration
Oxygen-free process gas or substitute
gas (O
2
in N
2
)
Substitute gas, e.g. dried air
Magnos27
Oxygen-free process gas Process gas with known O
2
concentration
Magnos27 with substitute gas
calibration
Oxygen-free process gas or substitute
gas (O
2
in N
2
)
Substitute gas, e.g. dried air
Caldos27
Sample component-free test gas or
process gas
Test gas or process gas with a
known sample gas concentration
Caldos27 with a
suppressed measuring range
Test gas with a sample component
concentration near the starting point of
the measuring range
Test gas with a sample
component concentration near
the end point of the measuring
range
Caldos27 with single-point
calibration
Test gas with a known and constant rTC
value (standard gas; possibly also dried
room air)
–
* Test gas mixture for multiple sample components possible if no cross-
sensitivity is present
