Installing the Gas Analyzer 51
Uras26: Gas Connections for Pipelines
(internal gas lines executed as stainless steel pipes)
6
Pressure sensor
Design: Screwed fitting with hose nozzle (stainless steel 1.4305/SAE 303) for hose with
4 mm inner diameter (supplied)
11
Sample gas inlet
12
Sample gas outlet with one sample cell
13
Sample gas outlet with two sample cells in series
Design: 1/8 NPT female thread (stainless steel 1.4305/SAE 303) for threaded
connections (not supplied)
Note: The oxygen sensor, the option "Integrated gas feed" and the version with
separate gas feed paths are not possible.
Caldos27: Gas Connections
1
Sample gas inlet
2
Sample gas outlet
Design: 1/8 NPT female thread (stainless steel 1.4305/SAE 303)
Connection of flexible tubes: straight screwed fittings (PP) with nozzles for flexible
tubes with inside diameter = 4 mm (supplied)
Connection of pipelines: Threaded connections (not supplied)
Note: The sample gas outlet gas path 1 of the Uras26 is connected ex works to the
sample gas inlet of the Caldos27.
