E: GCE7003225P0101
20 DISTRIBUTION SOLUTION EK6 – MEDIUM VOLTAGE EARTHING SWITCH 12…40,5 KV – 25–50 KA
1) including earthing contact (Weight 3 Pieces: 1,8 kg)
E = Earthing switch, H = Auxiliary switch, L = Rating plate,
SE = Control electrode varies with panel design,
X = View direction for switch position indicator,
Y = View direction for switch position indicator,
S = Operating/Switching angle, C = ON, O = OFF
• See dimensional drawing GCEM 360 524,
sheet 1, for shaft profi le
Caution!
Observe the notes in section rules for installation.
Contact blade distance: 8 ± 0,3 mm
Contact thickness: 9 mm
Contact force: 353 N
Contact spring force (cup springs): 376 N
Operating angle: 90
Switching angle: 90
Part number Type p a c g f Md OFF Md ON Weight kg
Earthing switch EK6
24 kV-Types
Dimensional drawing
GCEM700092, Sheet 6
