74 EL3060 CONTINUOUS GAS ANALYZERS | OI/EL3060-EN REV. A
Suppressed measuring ranges
If suppressed measuring ranges with a suppression ratio of be more than 1:5
have been set up in the Magnos206 analyzer, a special adjustment of the
pressure sensor which is installed as standard has been carried out ex works;
in this case, substitute gas calibration is also not installed in the analyzer.
Test gases
Analyzer Test gas for zero-point calibration
and single-point calibration
Test gas for end-point calibration
Magnos206 Oxygen-free process gas Process gas with known O
2
concen-
tration
Magnos206 with sup-
pressed measuring range
Test gas with O
2
concentration near
the starting point of the measuring
range
Test gas with O
2
concentration near
the end point of the measuring range
Magnos206 with single-
point calibration
Test gas with O
2
concentration in an
existing measuring range or ambient
air. Same moisture content as pro-
cess gas.
–
Magnos206 with substitute
gas calibration
Oxygen-free process gas or substi-
tute gas (O
2
in N
2
)
Substitute gas, e.g. dried air
CAUTION
In order to avoid accumulations of explosive gas mixtures, do not use air as
a test gas for single-point calibration when measuring flammable gases!
Dew point
The dew point of the test gases must be approximately the same as the dew
point of the sample gas.
