Lifting Instructions - AKD6/8/10 Emax2 600A - 2000A Retrofill Breakers

Retrofill

Breaker

Fig. 5A

Fig. 5B

Fig. 5C

1. For A se KD6, 8 & 10 small frames Emax2.2 Retrofill ker, uBrea

lifting device A as shown in Table 2 along with a

for ing.suitable hoist lift

2. Make sure the lifting device is secured and locked

with the hoist.

3. Lifting hooks (Item no.2, Table 2) can open in/out

within an angle of 7 in the vertical plane

± ° .

4. Lifting hooks can be engaged on the spreader bar

(Item no.1, Table 2) using any one of the two slots as per

the location of the hooking points in the Retrofill Breaker.

. Make sure that the 5 hooks are engaged in the slots

provided as shown in fig. 5C.

. the steady 6 While lifting hold Retrofill Breaker and

c it ontinue to guide , while checking both sides and

both underneath, so that sets of pins can be lowered

the of AKD6 switchgearand lined up easily with rail slots .

. Once the is resting in the rail lots, 7 Retrofill Breaker s

lifting hooks and munhook the ove the hoisting apparatus

out of the way.

Lifting Instructions

* Refer Table 2

2TSA451029P0000 Rev-B
