ESP630 Product Manual
1KHW002104 / Ed01a page 13 of 29 ABB
2 Switch Installation
2.1 Package Contents
• One Stackable ESP630 3x24Ax;
• Two mounting brackets already attached to the switch;
• One AC power cord.
2.2 Installation Guidelines
Before you choose a location to install the switch, make sure to follow the guidelines below:
• Choose a location where you can easily access the RJ-45 ports and that allows the LEDs to be
visible.
• The site’s temperature should be kept within 0 to 50 degrees Celsius and its humidity within 10 to
90% non-condensing.
• Do not restrict airflow by providing approximately 5 centimeters (2 inches) of space on all side of
the device.
• Locate the switch near a power source.
2.3 Installing the Switch without a Rack
To use the switch outside a rack, you may want to remove the side brackets that come attached to the
switch. Use a Phillips screwdriver to remove them.
After removing the brackets, choose a flat surface near an AC power source to place the switch.
