Recommendations for positioning
—
12 Recommendations for positioning.
30°
R
CT
min R5
The maximum stresses in the oil at the surface of the
conductor insulation must be limited to the normal values
for insulated conductors and similar components in the
same transformer. The adjacent recommendations are
intended as guidelines when complete calculations are not
carried out.
—
Table 11. Recommendations for positioning.
Type GSB CT (mm) R (mm)
