39 ELECTRONIC COMPACT STARTER | MANUAL
—
6.6 Short circuit protection
Single mounting
Single mounting means that one manual motor starter protects one HF-Starter. The maximal current of the motor defines
the size of the short circuit protection device (SCPD) and which HF-Starter is best to take.
Please find all installation proposals in table 15 for 500 V AC and table 16 for 415 V AC.
HF-Starter Iq
[kA]
SCPD Max. Current
[A]
Max. Voltage
[V AC]
HF0.6 35 MO132-0.63 0.075 500
HF0.6 35 MO132-0.63 0.63 500
HF2.4 35 MO132-0.63 0.63 500
HF2.4 35 MO132-1.0 1 500
HF2.4 35 MO132-1.6 1.6 500
HF2.4 35 MO132-2.5 2.4 500
HF9 35 MO132-1.6 1.6 500
HF9 35 MO132-2.5 2.4 500
HF9 35 MO132-4.0 4.0 500
HF9 35 MO132-6.3 6.5 500
HF9 35 MO132-10 9
1)
500
Table 15 Type 1 coordination of HF-Starter with Manual Motor Starter MO132 at 500 V AC
1) HF9 variants are able to switch 6.5 A in utilization category AC-53a and 9 A in AC-51.
HF-Starter Iq
[kA]
SCPD Max. Current
[A]
Max. Voltage
[V AC]
HF0.6 70 MO132-0.63 0.075 415
HF0.6 70 MO132-0.63 0.63 415
HF2.4 70 MO132-0.63 0.63 415
HF2.4 70 MO132-1.0 1 415
HF2.4 70 MO132-1.6 1.6 415
HF2.4 70 MO132-2.5 2.4 415
HF9 70 MO132-1.6 1.6 415
HF9 70 MO132-2.5 2.5 415
HF9 70 MO132-4.0 4.0 415
HF9 70 MO132-6.3 6.5 415
HF9 35 MO132-10 9
2)
415
Table 16 Type 1 coordination of HF-Starter with Manual Motor Starter MO132 at 415 V AC
2) HF9 variants are able to switch 6.5 A in utilization category AC-53a and 9 A in AC-51.
