1.2 Product combinations
In combination with the HF-range, ABB recommends using power supply CP-E 27/0.75 (1SVR427030R0000). With an output
current of 0.75 A, it is possible to connect up to 18 electronic compact starters.
Function Product Description Product name Order code
Power supply Power supply for compact
starters
24 V DC rated output voltage CP-E 24/0.75 1SVR427030R0000
Control input Pilot devices NO modular contact block MCB-10 1SFA611610R1001
Push button MP2-10x 1SFA611101R100X
Modular holder MCBH-00 1SFA611605R1100
DIN-rail adaptor MA1-8131 1SFA611920R8131
Remote reset Reset button 1 NO
Contact block for rear
mounting
MCB-10B 1SFA611610R2001
Push button MP1-10x 1SFA611100R100X
Modular holder MCBH-00 1SFA611605R1100
Emergency switching off Emergency switch Switch CE4P-10R-02 1SFA619551R1051
Interlocking - switch Switch Two-position selector switch M2SS5-10B 1SFA611204R100X
Modular holder MCBH-00 1SFA611605R1100
NO modular contact block
(2 pc.)
MCB-10 1SFA611610R1001
NC modular contact block
(2 pc.)
MCB-01 1SFA611610R1010
Safety related applications Safety relay Sentry SSR10 2TLA010050R0000
Sentry USR 10 2TLA010070R0000
Table 1 Product combinations
—
1.3 Explanation of terminals
Divergent details are shown for each type in the following chapters, in which the various functions of the terminals are also
explained.
All settings and adjustments are made directly at the electronic compact starter. The exception is HF9-R-24VDC where no
adjustments are possible and no protection function is integrated.
The LEDs have multiple functions, such as indicating the exact parametrized nominal current (see chapter 3.3), displaying the
status for diagnostics (see chapter 4.4) and showing the operation status.
9 ELECTRONIC COMPACT STARTER | MANUAL
