48 ELECTRONIC COMPACT STARTER | MANUAL
—
8.3.2 Disconnecting ground E (ꞱE) to safety relay
The safety relay and the electronic compact starter can be connected to the same supply voltage.
It is not necessary to connect to two different supplies.
—
32 SSR single channel connection to ⊥ E
µController
M
3 ~
ON MAN RES AUT96
Signal
95 97
1/L1 3/L2 5/L3
2/T1 4/T2 6/T3
Device and wire protection
U
S
U1
V1
PE
W1
14 24 34 42A2 X4 X1
Sentry SSR10
S3
A1 T1 R1 T2 R2 13 23 33 41
E
∆∇ ∆∇
S2
S2
+ 24 V DC
L1
L2
L3
N
0 V DC
To learn more about the different wiring types please follow this link.
