ABB HT577436 User Manual

Operation Manual / A130-H.. - A140-H..
13 Spare parts / 13.3 Spare part – Illustrations
© Copyright 2021 ABB. All rights reserved. HZTL4030_EN Rev.G July 2021
Air suction branch radial
82010*
82005
82006
82000
82008
82007
* = Available within the spare part set HZTL443012 Mod. D
Fig.60: SPI Air suction branch radial
Part no. Designation
82000 Air suction branch
82005 Screw plug
82006 Gasket
82007 Screw plug
82008 Gasket
82010* O-ring
Table52: Spare parts - Air suction branch radial
Page 116 / 122
