ABB HT597151 - Fig. 4: Locations of the Rating Plates; Locations of the Rating Plates

Operation Manual / 4 Product description / A100-M axial
1 Introduction / 1.6 Locations of the rating plates
© Copyright 2020 ABB. All rights reserved. HZTL4033_EN Rev.E May 2020
1.6 Locations of the rating plates
Fig.4: Locations of the rating plates
One rating plate (01) each is attached on the left and the right side of the foot of the tur-
bocharger.
On turbochargers with insulation supplied by ABB, at least one additional rating plate is at-
tached to the insulation of the gas outlet casing.
Page 7 / 113
