Chapter 2
MicrOS 410 Installation Guide 19
Mount the MicrOS 410 on a metal pole
1. Select a mounting location. You can attach the MicrOS 410 to any pipe or pole with
diameter between 2 inches and 5 inches.
2. Slip the flat portion of the clamp under the inner slot of the pole bracket.
3. Use the clamp to attach the pole bracket to the pole, making sure that it is level. Depending
upon the diameter of the pole, you may need to use a single small clamp, single large clamp,
or pair of large clamps joined together to reach around the pole.
4. Attach the MicrOS M-type bracket to the MicrOS 410 as shown in Figure 2.
5. Attach the mounting bracket of the unit to the pole bracket.
— Insert one screw through the hole at the top of the mounting bracket to the hole at the top
of the pole bracket.
— Insert the other screw through the curved slot track in the mounting bracket to the hole in
the middle of the pole bracket just above the clamp slot.
6. Level the mounting bracket by rotating the unit along the curved slot tracks. Tighten the
screws.
To continue installing the MicrOS 410, see
“Connecting Power and Data Cables” on page 21.
