ABB MicrOS 410 - Figure 2 Metal Pole Mounting; Table 3 Metal Pole Mounting Callouts

Chapter 2 
MicrOS 410 Installation Guide 18
Figure 2 Metal Pole Mounting
Table 3 Metal Pole Mounting Callouts
Item
Description
1 MicrOS 410 Unit
2 Mounting bracket
3 M8 x 16mm screw (2 pieces)
4 M8 split washer (2 pieces)
5 M8 flat washer (2 pieces)
6 M8 nut (2 pieces)
7 M8 x 12mm screw (2pieces)
8 Mounting bracket
9 Hose clamp, 5” (2 pieces)
