Chapter 3
MicrOS 410 Installation Guide 30
Table 11 Interfaces
Specification Value
Ethernet Interface
IEEE 802.3 10/100BaseT
• Auto sensing
• Maximum Distance (ft):
550 (10BaseT Duplex Setting)
300 (100BaseT Duplex Setting)
• RJ45 connector
Serial Interface
RS-232
• Auto sensing
• Maximum Distance 550 ft
• RJ45 connector
RS-485
• Auto sensing
• Maximum Distance 500 ft
• RJ45 connector
802.11b/g/n Wireless Interface
Standard IEEE 802.11b/g/n Wi-Fi
Frequency Range
2400 to 2483 MHz ISM Band (11 channels) FCC Part 15
2400 to 2483 MHz ISM Band (13 channels) ETSI
Modulation 802.11g/n - OFDM (64-QAM, 16-QAM, QPSK, BPSK)
802.11b - DSSS (DBPSK, DQPSK, CCK)
Rx Sensitivity
-97dBm @ 1 Mbps -96dBm @ 6 Mbps
Tx Power FCC/IC 20.0dBm -35dBm (EIRP) set in 1dB units
ETSI/EU 5-20dBm set in 1dB units
Table 12 Protection/Power
Specification Value
Antenna Protection <= 0.5μJ for 3kA @ 8/20μS Waveform
EN61000-4-2 Level 4 ESD Immunity
EN61000-4-5 Level 4 Surge Immunity
Data Port Protection EN61000-4-2 Level 4 ESD Immunity
EN61000-4-5 Level 4 Surge Immunity
Power
Power Input Power input: PoE (7-36 VDC)
Power Consumption 3 W typical
