ABB NextMove e100 Quick Installation Guide

46 Snabbinstallationshandbok – NextMove e100
X1 - 24 V likström-försörjning
X2, X3 - Stegmotorstyrutgångar
X4, X11 - Digitala utgångar
X5, X6, X7 - Motoråterkoppling
Description Value
Input power
Nominal input voltage
Power consumption
24 V DC (±20%)
50 W (2 A @24 V)
Description Unit NXE100-16xxDx NXE100-16xxSx
Output type RS422 differential
outputs
Darlington
step (pulse) and
direction
Maximum output frequency 5 MHz 500 kHz
Output current 20 mA
(typical)
50 mA
(maximum sink,
per output)
Description Unit Value
USR V+ supply voltage
Nominal
Minimum
VDC
24
12
Output current
Max. source per output, one output on
Max. source per output, all outputs on
Maximum total output current
mA DOUT0-7 DOUT8-11
350 350
62.5 125
500 500
Update interval (Mint) Immediate
Switching time
No load on output
With 7 mA or greater load
100 ms
10 µs
Description Unit Value
Encoder input RS422 A/B Differential, Z index
Maximum input frequency
quadrature
MHz
20
Output power supply to encoders 5V (±5%)
500 mA (maximum total for all axes)
Maximum allowable cable length 30.5 m (100 ft)
