快速安装指南
– NextMove
e100
机械安装
用安装螺丝通过四个安装孔将控制器固定到安装座上。
140
(
5.51
)
129
(
5.08
)
170
(
6.69
)
250
(
9.84
)
40.3
(
1.59
)
A
A
B
C
A
= 4.5 mm
B
= 10 mm
C
= 1
1 mm
所有尺寸均以
mm
（英寸）表示
图纸未按比例
安装锁眼和插槽详情
重量
:
约
700 g
（
1.5
lb
）
LT03
05A01
