AUTOMATIC TRANSFER SWITCH, OTM_C_21D
—
4. Interface and Settings
—
4.1 Buttons
Figure 11. Buttons
Table 5. Buttons
Button Function Remarks
I ON
Transfer to LN1 Only available in automatic mode and remote
test mode
O OFF
Transfer to 0 position
II ON
Transfer to LN2
Auto
Select autiomatic mode, fault clearance and reset
Transfer using bypass transfer delay and return delay.
