PositionMaster EDP300 DIGITAL POSITIONER | OI/EDP300-EN REV. D 63
Menu: Digital Input
Menu / parameter Value range Description
Input/Output / Digital Input
DI Function Off
Hold Last SP
Hold User SP
Hold Last Pos.
Vent. Out1
Vent. Out2
Freeze Outputs
Partial Stroke Test
Service Required
Safety Position
Conf. Locked
Panel Locked
Locked
• Off – No function
• Hold Last SP – Last set point is retained
• Hold User SP – Substitute value for set point (defined in ‘DI Default Setup.’)
• Hold Last Pos. – Hold previous position
• Vent. Out1 – Vent Output 1
• Vent. Out2 – Vent Output 2
• Freeze Outputs – Close pneumatic outputs
• Partial Stroke Test – Start Partial Stroke Test
• Service Required – Issue diagnosis bit via binary feedback
• Safety Position – Approach safety position
• Conf. Locked – Block local configuration
• Panel Locked – Block local operation
• Locked – Block all operation and setting options.
DI Default SP 0 to 100% The position defined using this parameter is approached when the ‘Digital Input’ function has been set
to ‘Hold User SP’ and the digital input has been activated.
DI Logic Active High, Active Low Use this parameter to configure the contact logic for activating the digital input.
Note
For the following parameters, the contact logic is always ‘Active Low’ or ‘Off’:
• Safety Position
• Conf. Locked
• Panel Locked
• Locked
