80 PositionMaster EDP300 DIGITAL POSITIONER | OI/EDP300-EN REV. D
… 14 Supplemental specifications
Ambient conditions
Ambient temperature range
During operation, storage,
and transport
Æ40 to 85 °C (Æ40 to 185 °F)
Æ40 to 100 °C (Æ40 to 212 °F)*
* Increased temperature range only with EDP300 Remote Sensor.
Relative humidity
During operation with housing
closed and air supply switched on
95 % (annual average), condensation
permissible
Transport and storage 75 % (annual average)
15 Additional documents
Note
All documentation, declarations of conformity and certificates
are available in ABB's download area.
www.abb.com/positioners
Trademarks
HART is a registered trademark of FieldComm Group, Austin, Texas, USA
16 Accessories
Extension modules
Mechanical position indicator
Indicator disk in housing cover linked with device feedback
shaft.
Contactless position sensor (optional)
In difficult ambient conditions (constant valve movements, for
example, which are transmitted to the sensor axis by the
process pressure), the positioner can be fitted with a
contactless position sensor.
Pressure option
The pressure option comprises 3 absolute pressure sensors
which facilitate pressure-based valve diagnostics (valve
signature, for example).
The supply air pressure and the output pressures can also be
monitored. The zero points of the pressure sensors can be
calibrated both locally on the device and using the DTM.
These options are also available for retrofitting by Service.
Accessories
Mounting material
• Attachment kit for linear actuators in accordance with DIN /
IEC 534 / NAMUR
• Attachment kit for rotary actuators in accordance with VDI /
VDE 3845
• Attachment kit for integral mounting
• Attachment kit for actuator-specific mounting
Pressure gauge block
With pressure gauges for supply air and output pressure.
Pressure gauges with housing ø 28 mm (1.10 in), with connection
block in aluminum, black
PC adapter for communication
USB HART® Modem for HART® communication (see data sheet
63-6.71)
Control program for operation and parameterization on
a PC
DAT200 Asset Vision Basic with DTM for EDP300 (see data sheet
DS/DTM/DAT200)
