ProcessMaster FEP610, HygienicMaster FEH610 | OI/FEP610/FEH610-EN Rev. B 89
Nominal diameter
[mm (inch)]
Nominal pressure
rating
Maximum tightening torque [Nm]
Hard / soft rubber PTFE, PFA, ETFE Ceramic carbide
2) 3) 2) 3) 2) 3)
DN 300 (12“) PN10 58.79 38.45 91.29 94.65 91.29 94.65
PN16 122.4 85.64 113.9 114.8 113.9 114.8
PN25 180.6 130.2 151.1 106.9 151.1 106.9
PN40 233.4 237.4 254.6 252.7 254.6 252.7
CL150 90.13 50.37 203.5 198 203.5 198
CL300 333.3 216.4 421.7 259.1 421.7 259.1
DN 350 (14“) PN10 69.62 47.56 72.49 75.22 72.49 75.22
PN16 133.6 93.61 124.9 104.4 124.9 104.4
PN25 282.3 204.3 226.9 167.9 226.9 167.9
CL150 144.8 83.9 270.5 263 270.5 263
CL300 424.1 252.7 463.9 259.4 463.9 259.4
DN 400 (16“) PN10 108.2 75.61 120.1 113.9 120.1 113.9
PN16 189 137.2 191.4 153.8 191.4 153.8
PN25 399.4 366 404 246.7 404 246.7
CL150 177.6 100 229.3 222.8 229.3 222.8
CL300 539.5 318.8 635.8 328.1 635.8 328.1
DN 450 (18“) CL150 218.6 120.5 267.3 192.3 267.3 192.3
CL300 553.8 327.2 660.9 300 660.9 300
DN 500 (20“) PN10 141.6 101.4 153.9 103.5 153.9 103.5
PN16 319.7 245.4 312.1 224.8 312.1 224.8
PN25 481.9 350.5 477.1 286 477.1 286
CL150 212.5 116 237.3 230.4 237.3 230.4
CL300 686.3 411.8 786.8 363.1 786.8 363.1
DN 600 (24“) PN10 224.7 164.8 238.7 149.1 238.7 149.1
PN16 515.1 399.9 496.7 365.3 496.7 365.3
PN25 826.2 600.3 750.7 539.2 750.7 539.2
CL150 356.6 202.8 451.6 305.8 451.6 305.8
CL300 1188 719 1376 587.4 1376 587.4
DN 700 (28“) PN10 267.7 204.9 On request On request 267.7 204.9
PN16 455.7 353.2 On request On request 455.7 353.2
PN25 905.9 709.2 On request On request 905.9 709.2
CL150 364.1 326.2 449.2 432.8 364.1 326.2
CL300 1241 On request On request On request 1241 On request
DN 750 (30“) CL150 423.8 380.9 493.3 442 423.8 380.9
CL300 1886 On request On request On request 1886 On request
DN 800 (32“) PN10 391.7 304.2 On request On request 391.7 304.2
PN16 646.4 511.8 On request On request 646.4 511.8
PN25 1358 1087 On request On request 1358 1087
CL150 410.8 380.9 493.3 380.9 410.8 380.9
CL300 2187 On request On request On request 2187 On request
DN 900 (36“) PN10 387.7 296.3 On request On request 387.7 296.3
PN16 680.8 537.3 On request On request 680.8 537.3
PN25 1399 1119 On request On request 1399 1119
CL150 336.2 394.6 511 458.5 336.2 394.6
CL300 1972 On request On request On request 1972 On request
2) Flange material: steel.
3) Flange material: stainless steel.
