Hardwire DI Stop input
signal state
0 = DI Stop signal
inactive
1 = DI stop signal active
Hardwire DI Reset input
signal state
0 = DI Reset signal
inactive
1 = DI Reset signal
active
0 = Softstarter is not in
top of ramp
1 = Softstarter is in top
of ramp (bypass closed)
0 = No faults are active,
control supply voltage is
stable and motor will
start when start
command is given
1 = Fault is active or
control supply voltage is
not stable and motor will
not start when start
command is given
1) Auto mode reflects the control state of the Softstarter. This is affected by a combination of:
The Auto mode input signal from the Modbus master (protocol address 0105h in the digital output telegram)
The state of the Local/Remote switch on the Fieldbus Plug Accessory.
