FBP FieldBusPlug
DeviceNet, MODBUS-RTU and CANopen accessories, ordering details
Accessories for the DeviceNet, MODBUS-RTU and CANopen bus connector
DeviceNet, MODBUS-RTU and CANopen round cable for bus junctions
Ready-made bus cable with an M12 connector and an open cable end.
Designation Cable length Type Order code
Pack
ing
piece
Weight
kg
1 piece
Round cable with female connector 0.50 m DNF11-FBP.050 1SAJ 923 002 R0005 1 0.04
Round cable with male connector 0.50 m DNM11-FBP.050 1SAJ 923 003 R0005 1 0.04
DeviceNet, MODBUS-RTU and CANopen round cable for bus extension
Ready-made bus cable with M12 male and female connectors
Designation Cable length Type Order code
Pack
ing
piece
Weight
kg
1 piece
Extension cable 1.00 m DNX11-FBP.100 1SAJ 923 001 R0010 1 0.08
Extension cable 3.00 m DNX11-FBP.300 1SAJ 923 001 R0030 1 0.20
Extension cable 5.00 m DNX11-FBP.500 1SAJ 923 001 R0050 1 0.31
Round cable 100.00 m DNC11-FBP.999 1SAJ 923 004 R0001 1 5.60
DeviceNet, MODBUS-RTU and CANopen round cable connectors
Bus cable and coupling accessories
Designation Type Order code
Pack
ing
piece
Weight
kg
1 piece
Male connector for round cable DNM11-FBP.0 1SAJ 923 005 R0001 5 0.15
Female connector for round cable DNF11-FBP.0 1SAJ 923 006 R0001 5 0.15
DeviceNet, MODBUS-RTU and CANopen termination resistor
Designation Type Order code
Pack
ing
piece
Weight
kg
1 piece
Termination Resistor, 120 Ohm DNR11-FBP.120 1SAJ 923 007 R0001 1 0.02
