1SFC132081M0201 | Installation and commissioning manual | Troubleshooting 161
10.3 Overview of faults, protections and warnings
This table shows in which state the different indications
for protections, faults and warnings can show.
Event code* Motor control states **
(Hexadecimal)
Stand by
Start prerequisites
Pre-start
Init start
Start Ramp
Close bypass
Top of ramp
Open bypass
Stop ramp
Separate func
Protections
Electronic overload P0Fxx X X X X X X X X X X
Locked rotor P10xx X
Phase reversal P11xx X X X X X X X X
Current imbalance P12xx X
Current underload P13xx X
User defined protection P14xx X X X X X X X X X X
Ground fault P15xx X X X X X X X X
Overvoltage P16xx X
Under voltage P17xx X
Voltage imbalance P18xx X X X X X X X X
PT100 protection P19xx X X X X X X X X X X
PTC protection P1Axx X X X X X X X X X X
Power factor underload P1Bxx X
Too long current limit P1Cxx X X
Bypass open fault P1Dxx X
Fieldbus communication failure P1Exx X X X X X X X X X X
24V output P1Fxx X X X X X X X X X X
HMI failure P20xx X X X X X X X X X X
Extension IO failure P21xx X X X X X X X X X X
Max number of starts per hour P22xx X
Auto-restart time-out P31xx X X X X X X X X X X
Too long start time P32xx X X
Frequency range P33xx X X X X X X X X
* Only the first 2 digits are important
** For motor control states description, see chapter 7 Functions
